EV7050 Voltage-Controlled SAW Oscillator

Achieve ultra-low jitter at high frequencies


► Zur deutschen Pressemitteilung



Munich, May 14, 2018 – Epson Europe Electronics GmbH (“Epson”) offers EV7050 Voltage-Controlled SAW Oscillator. Designed for high-speed optical links, EV7050 VCSOs achieve extremely low jitter of 18fs 12 kHz - 20 MHz at high frequency of 2.2 GHz.

Using Epson’s proprietary SAW and coating technology, EV7050 Series SAW oscillators feature LVPECL output and support a frequency range of 0.6-2.2GHz, are packed in a 7 mm x 5 mm package and have a track record of zero field failures in 18 years.

The EV7050 series is available with an operating temperature range of -10 to +85 °C and an APR (Absolute Pull Range) of ±50 ppm or -40 to +85 °C with an APR of ±30 ppm.

Thanks to the outstanding phase noise performance, Epson’s EV7050 Series is ideally suited for applications in high speed optical modules, remote radio heads (RRHs), test and measurement equipment or any application requiring high-speed ADCs and/or DACs.

Features

  • Low phase noise: 18 fs 12 kHz – 20 MHz @ 2.2 GHz
  • Frequency Range: 0.6-2.2 GHz
  • Small size: 7.0 mm x 5.0 mm x 1.6 mm
  • Low  power: 148 mA @ 2.2 GHz
  • High reliability, Zero field failures in 18 years

Releated Links

Please see the link below fur further details about these products.

https://www5.epsondevice.com/en/products/vcxo/ev7050ean.html



About Epson
Epson is a global technology leader dedicated to connecting people, things and information with its original efficient, compact and precision technologies. With a lineup that ranges from inkjet printers and digital printing systems to 3LCD projectors, watches and industrial robots, the company is focused on driving innovations and exceeding customer expectations in inkjet, visual communications, wearables and robotics.
Led by the Japan-based Seiko Epson Corporation, the Epson Group comprises more than 76,000 employees in 87 companies around the world, and is proud of its contributions to the communities in which it operates and its ongoing efforts to reduce environmental impacts.
global.epson.com/

About Epson Europe Electronics GmbH

Epson Europe Electronics GmbH is a marketing, engineering and sales company and the European Headquarters for electronic devices of the Seiko Epson Corporation, Japan. Since 1989 headquartered in Munich/Germany with 50 employees, Epson Europe Electronics GmbH has several European sales representatives and has a European-wide network of distributors. Epson Europe Electronics provides value added services for Semiconductors, Sensors, Sensing Systems and Timing Devices targeted to all markets like industrial, automotive, medical and communication. Epson products are recognized for energy saving, low power, small form factors and rapid time to market. Information about Epson Europe Electronics GmbH is available in the Internet under www.epson-electronics.de



EV7050 spannungs-gesteuerte SAW Oszillatoren

Erreichen extrem niedrigen Jitter bei hohen Frequenzen

München, 14. 5. 2018 – Epson Europe Electronics GmbH („Epson“) bietet mit der EV7050-Serie spannungs-gesteuerte SAW Oszillatoren (VCSO) an, die eine akustische Oberflächenwellen-Technologie  verwenden. Epson’s EV7050 VCSOs sind ausgelegt für optische Hochgeschwindigkeitsverbindungen und erreichen einen extrem geringen Jitter von 18fs 12 kHz bis 20 MHz bei einer Hochfrequenz von 2,2 GHz.

Die EV7050 Serie verwenden Epson’s urheberrechtlich geschützte SAW- und Beschichtungstechnologie, bieten einen LVPECL-Output, unterstützen einen Frequenzbereich von 0,6-2,2 GHz und weisen eine Leistungsbilanz von null Feldausfällen in 18 Jahren auf.

Epson’s EV7050 VCSOs sind verfügbar mit einer Betriebstemperatur von -10 bis +85 °C und einem Absoluten Pull-Bereich (APR) von ±50 ppm oder mit einer Betriebstemperatur von -40 bis +85 °C und einem APR von ±30 ppm. Die EV7050 Serie ist in einem 7,0 x 5,0 mm2 Gehäuse untergebracht.

Dank der herausragenden Phasenrauschleistung ist Epson’s EV7050 Serie ideal geeignet für Anwendungen in optischen Hochgeschwindigkeitsmodulen, Remote Radio Heads (RRHs), Test- und Messgeräten oder Anwendungen, die ADCs und/oder DACs mit hoher Geschwindigkeit benötigen.

Besondere Merkmale

  • Niedriger Phasenrausch: 18 fs 12 kHz – 20 MHz @ 2,2 GHz
  • Frequenzbereich: 0,6-2,2 GHz
  • Kleines Gehäuse: 7,0 x 5,0 x 1,6 mm3
  • Geringer Stromverbrauch: 148 mA @ 2,2 GHz
  • Hohe Ausfallsicherheit, null Feldausfälle in 18 Jahren

Mehr Informationen

https://www5.epsondevice.com/en/products/vcxo/ev7050ean.html



Über die Epson Gruppe
Als eines der weltweit innovativsten Unternehmen ist es Ziel von Epson, mit vielfältigen Lösungen für das Büro, das Zuhause sowie für Industrie und Handel Kundenerwartungen immer wieder zu übertreffen. Das Produktangebot basiert auf kompakten, stromsparenden und mit höchster Präzision arbeitenden Epson Technologien und reicht von Tintenstrahldruckern, Drucksystemen und 3LCD-Projektoren bis hin zu Uhren und Industrierobotern. Die Epson Gruppe gehört zu der japanischen Seiko Epson Corporation und beschäftigt weltweit mehr als 76.000 Mitarbeiter in 87 Unternehmen. Epson ist stolz auf seinen globalen Beitrag zum Umweltschutz und auf das soziale Engagement an den Standorten seiner Niederlassungen. global.epson.com/

Über Epson Europe Electronics GmbH
Epson Europe Electronics GmbH ist eine Marketing-, Engineering- und Vertriebsgesellschaft der Seiko Epson Corporation, Japan. Seit der Firmengründung 1989 ist der Hauptsitz in München. Epson Europe Electronics GmbH hat ca. 50 Mitarbeiter, die den Vertrieb von Epson- Produkten unterstützen. Epson Europe Electronics GmbH vertreibt Produkte in Europa, Mittlerer Osten und Afrika und bietet "value added” Service für Halbleiter, Sensoren, Sensor Systeme und Taktgeber in allen Märkten wie Industrie, Automotive, Medizintechnik und Kommunikationstechnik. Epson Produkte sind bekannt für ”energy saving”, ”low power”, kleinste Baugrößen und einer kurzen Entwicklungs- und Produktionszeit. Informationen zu Epson Europe Electronics GmbH können im Internet unter www.epson-electronics.de abgerufen werden.
